Form Factor | M.2 2280 Single Side |
Capacity | 1TB, |
NAND Technology | SK hynix 128L 3D TLC NAND Flash |
Interface | PCIe 3.0 NVMe, up to 4 lanes |
Sequential Performance | Read : 3,500 MB/s
Write : 3,200 MB/s |
Random Performance | Read : 570K IOPS
Write : 600K IOPS |
Latency | Read 90us / Write 45us |
Queue Support | – Support up to 256 queues
– Support up to 1,024 queue depth for each queue |
Temperature Range Operation | – 0℃ to 70℃
– Temperature Sensor (SMART Attributes Bytes 02:01h) |
Reliability | MTBF : 1.5M hours
BER : 1 error in 1015 bits transferred |
Dimension | (22.00±0.15) x (80.00±0.15) x (Max. 2.23) mm |
Weight | Max 7.0g |
Voltage | 3.3V±5% |
Source : https://ssd.skhynix.com/gold_p31/
